The Marlin 7 is your best friend on the trail and wherever else you roll thanks to its confidence-boosting trail geometry. It finds the perfect balance between price and performance with a RockShox suspension fork that makes quick work of rocks and bumps in your path, and loads of gears from the SRAM NX Eagle 12-speed drivetrain.
*Please note – spec applies to all sizes unless listed separately
*Frame:
Size: XS
Alpha Silver Aluminium, curved top tube, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew
Size: S , M , ML , L , XL
Alpha Silver Aluminium, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew
*Fork:
Size: XS , S
RockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 42 mm offset for 27.5" wheel, 100 mm QR, 100 mm travel
Size: M , ML , L , XL
RockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 46 mm offset for 29" wheel, 100 mm QR, 100 mm travel
Hub front: Formula DC-20 LW, alloy, 6-bolt, 100x5 mm
Hub rear: Formula DC-22LW, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm
Skewer rear: 173x5 mm QR
*Rim:
Size: XS , S , M , ML , L , XL
Bontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valve
Size: M , ML , L , XL
Bontrager Kovee, double-wall, Tubeless-Ready, 32-hole, 23 mm width, Presta valve
*Tyre:
Size: XS , S
Maxxis Rekon, tubeless ready, EXO casing, folding bead, 60 tpi, 27.5x2.40''
Size: M , ML , L , XL
Maxxis Rekon, tubeless ready, EXO casing, folding bead, 60 tpi, 29x2.40''
Rim strip: Bontrager TLR
Shifter: SRAM SX Eagle, 12-speed
Rear derailleur: SRAM NX Eagle, 12-speed
*Crank:
Size: XS , S , M
SRAM SX Eagle, 30T steel ring, 49 mm chainline, 170 mm length
Size: ML , L , XL
SRAM SX Eagle, 30T steel ring, 49 mm chainline, 175 mm length
Bottom bracket: Truvativ Powerspline, 73 mm, threaded cartridge, 118 mm spindle
Cassette: SRAM PG-1210 Eagle, 11-50, 12-speed
Chain: SRAM SX Eagle, 12-speed
Pedal: VP-536 nylon platform
Saddle: Bontrager Verse Short, stainless steel rails
*Seatpost:
Size: XS , S
TranzX JD-YSI34, 100 mm travel, internal routing, 31.6 mm, 350 mm length
Size: M
TranzX JD-YSI34, 125 mm travel, internal routing, 31.6 mm, 405 mm length
Size: ML , L
TranzX JD-YSI34, 150 mm travel, internal routing, 31.6 mm, 456 mm length
Size: XL
TranzX JD-YSI34, 170 mm travel, internal routing, 31.6 mm, 500 mm length
*Handlebar:
Size: XS
Bontrager alloy, 31.8 mm, 5 mm rise, 690 mm width
Size: S
Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm width
Size: M , ML , L , XL
Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
Grips: Trek Line Comp, nylon lock-on
*Stem:
Size: XS , S
Bontrager Comp, 31.8 mm, 7-degree, 35 mm length
Size: M , ML , L
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length
Size: XL
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 60 mm length
Head set: Semi-integrated, 1-1/8"
Brake: Shimano MT200 hydraulic disc
*Brake rotor:
Size: XS , S , M , ML , L , XL
Shimano RT26, 6-bolt, 160 mm
Size: M , ML , L , XL
Shimano RT26, 6-bolt, 180 mm
Brake Set: Shimano MT200 hydraulic disc
Weight: M - 14.15 kg / 31.2 lbs
Weight limit: This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice. The prices shown are the manufacturer's suggested retail prices.
Weights are based off pre-production products at time of publication. Weights may vary in final production.
Colour Options:
- Magic Mint
- Fury Red Fade
- Matte Dark Web/Clear Gloss
