| Frame |
Ultralight 300 Series Alpha Aluminum, Invisible Weld technology, tapered head tube, Control Freak internal routing, DuoTrap S compatible, flat mount disc, 142x12mm thru axle BB Standard: BB86/BB92, 86.5mm, Press Fit Tire Clearance: 28c Colors: Purple Abyss; Slate to Trek Black Fade; Matte Gravel / Gloss Quicksilver; Purple Flip |
|---|---|
| Fork |
Emonda SL full carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm thru axle |
| Bottom Bracket |
Shimano BB71, 86.5mm, PressFit |
| Headset |
FSA Integrated, sealed cartridge bearing, 1-1/8'' top, 1.5'' bottom |
| Stem |
Size: 47, Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 70mm length; Size: 50, Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 80mm length; Size: 52, 54, Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 90mm length; Size: 56, 58, Bontrager Elite, 31.8mm clamp, Blendr compatible, 7 degree, 100mm length; Size: 56, Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 100mm length; Size: 60, 62, Bontrager Elite, 31.8mm clamp, Blendr compatible, 7 degree, 110mm length |
| Handlebar |
Size: 47, 50, 52, Bontrager Comp VR-C, alloy, 31.8mm, 100mm reach, 124mm drop, 40cm width; Size: 54, 56, Bontrager Comp VR-C, alloy, 31.8mm, 100mm reach, 124mm drop, 42cm width; Size: 58, 60, 62, Bontrager Comp VR-C, alloy, 31.8mm, 100mm reach, 124mm drop, 44cm width |
| Saddle |
Size: 47, 50, 52, 54, 56, 58, 60, 62, Bontrager Montrose Comp, steel rails, 138mm width; Size: 47, 50, 52, Bontrager P3 Verse Comp, steel rails, 155mm width; Size: 54, 56, Bontrager P3 Verse Comp, steel rails, 145mm width |
| Seatpost |
Bontrager carbon, 27.2mm, 8mm offset, 330mm length Type: Rigid |
| Rear Derailleur |
Shimano 105 R7000, short cage, 30T max cog |
|---|---|
| Front Derailleur |
Shimano 105 R7000, braze-on |
| Crank |
Size: 47, 50, 52, Shimano 105 R7000, 50/34 (compact), 170mm length; Size: 54, 56, Shimano 105 R7000, 50/34 (compact), 172.5mm length; Size: 58, 60, 62, Shimano 105 R7000, 50/34 (compact), 175mm length |
| Shifters |
Shimano 105 R7020, 11 speed |
| Cassette |
Shimano 105 R7000, 11-28,11 speed |
| Chain |
Shimano 105 HG601, 11 speed |
| Brakes |
Shimano 105 hydraulic disc, flat mount Type: Hydraulic Disc |
| Rims |
Bontrager Affinity Disc, Tubeless Ready, 24-hole, 21mm width, presta valve |
|---|---|
| Spokes |
14g stainless steel |
| Front Hub |
Bontrager alloy, sealed bearing, centerlock disc, 100x12mm thru axle |
| Rear Hub |
Bontrager alloy, sealed bearing, centerlock, Shimano 11-speed freehub, 142x12mm thru axle |
| Tires |
Bontrager R1 Hard-Case Lite, wire bead, 60 tpi, 700x25c |
| Disc Rotors |
Shimano SM-RT70, centerlock, 160mm |
