FX 3 is a fitness hybrid built for riders who want speed, versatility, and a ride that feels fast from the first pedal stroke. Its lightweight aluminum frame, carbon fork, and active geometry keep handling quick and efficient, while a 10-speed Shimano CUES drivetrain and hydraulic disc brakes deliver smooth shifting and confident stopping power. Whether you’re commuting, getting in miles after work, or cruising rail trails on the weekend, FX 3 is ready to roll.
|
FRAMESET: |
|
|
Frame: |
Alpha Gold Aluminium, internal cable routing, rack & mudguard mounts, post mount disc, kickstand mount, 135x5 mm QR |
|
Fork: |
FX carbon, flat-mount disc, rack mounts, 410mm axle-to-crown, ThruSkew 5mm QR |
|
WHEELS: |
|
|
Hub Front: |
Formula DC-20, alloy, 6-bolt, 100x5 mm |
|
Skewer Front: |
139x5mm bolt-on |
|
Hub Rear: |
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm |
|
Skewer Rear: |
152x5mm QR |
|
Rim: |
Bontrager Tubeless Ready Disc, 32-hole, Presta valve |
|
Spokes: |
|
|
Tyre: |
|
|
Max. Tyre Size: |
700x40mm |
|
DRIVETRAIN: |
|
|
Shifter: |
Shimano CUES U6000 w/optical gear display, 10-speed |
|
Front Derailleur: |
Shimano Tourney TY606, 31.8/34.9 mm clamp, top swing, dual pull |
|
Rear Derailleur: |
Shimano CUES U6000 GS |
|
Crank: |
Size: XS, S, M |
|
Size: L, XL |
|
|
Bottom Bracket: |
Sealed cartridge, 68 mm |
|
Cassette: |
Shimano CUES LG300, LINKGLIDE, 11-48, 10-speed |
|
Chain: |
Shimano LG500 |
|
Pedal: |
Bontrager City Pedal |
|
Saddle: |
Bontrager H1 |
|
Max. Chainring Size: |
1x: 44T, 2x: 46/32 |
|
Seatpost: |
Size: XS, S, M Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm length |
|
Size: L, XL Bontrager alloy, 27.2 mm, 12 mm offset, 400 mm length |
|
|
Handlebar: |
Size: XS, S, M Bontrager Comp Lowriser, alloy, 31.8 mm, 15 mm rise, 600 mm width |
|
Size: L, XL Bontrager Comp Lowriser, alloy, 31.8 mm, 15 mm rise, 660 mm width |
|
|
Grips: |
Trek Ergonomic Comp, lock-on |
|
Stem: |
Size: XS, S Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 90 mm length |
|
Size: M, L, XL Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 100 mm length |
|
|
Brake: |
Shimano hydraulic disc, MT201 lever, UR300 calliper |
|
Brake Rotor: |
Shimano RT26, 6-bolt, 160 mm |
|
Max. Rotor Size: |
Max brake rotor sizes: 160mm front & rear |
|
WEIGHT: |
|
|
Weight: |
M – 11.65 kg/25.69 lb |
|
Weight Limit: |
This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg). |
*Please note – spec applies to all sizes unless listed separately
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
